Konecranes KBK aluminium workstation lifting systems

Light, durable and versatile lifting

  •


    Konecranes KBK aluminium workstation lifting systems satisfy the demanding requirements of clean workplaces and production lines with a lifting capacity of up to 2,000 kg. For precise and repetitive actions, especially on heavy loads, workers need reliable, easy-to-use crane that is quick to install, to follow tight production schedules, save costs and reduce downtime.

    The crane’s durable, anodized aluminium surface requires minimal maintenance and gives lifetime protection against corrosion. Lighter than steel by about 50%, it has less rolling resistance in manual applications. Offering exceptional utility and flexibility, the Konecranes KBK aluminium workstation lifting systems is available ceiling-mounted or freestanding, single or double girder, or even on a monorail.

  • Xk-a crane

Product Features

The Konecranes KBK aluminium workstation lifting system has the following product features:

•    Light and durable anodized aluminium structure
•    Modular system with multiple profile sizes
•    Different system configurations, including:

  • monorail

  • single and double girder bridges with articulated or rigid movement

  • freestanding structures

  • telescopic cranes

  • installations for manipulator handling

•    Manual or motorized trolleys and bridges
•    Smooth-running trolleys with low rolling resistance
•    Service hatch for easy trolley inspection and maintenance
•    Energy supply via festoon or integrated conductor lines or energy chain
•    Low headroom available
•    Lifetime protection against corrosion
•    Can be combined with steel runways and bridges



Technical Specifications

The Konecranes KBK aluminium workstation lifting systems has the following standard technical specifications:

  • Intended for indoor use

  • Design follows EC machinery directives

  • Ambient temperature range limits -10°C to +40°C

  • Corrosion category at least C2-M (acc. to DIN EN ISO 12944)

  • Crane control via pendant or radio

  • Up to 6 bridges on one runway

Performance data for single-girder cranes:

PROFILE SIZE

100

I

II-L

II

II-H

A12

A16

A18

A22

LOAD CAPACITY [KG]

GIRDER LENGTH (M)

80

3

6

8

8



5

8

8

8

125

3

5

8

8

14

4

6

8

8

250



3

7

8

13

2

4

7

8

500



2

4

7

11

2

3

4

6

1000





2

4

7





3

4

1600









6







3

2000









5







3



Performance data double-girder cranes:

PROFILE SIZE

100

I

II-L

II

II-H

A12

A16

A18

A22

LOAD CAPACITY [KG]

GIRDER LENGTH (M)
Steel Aluminium



5

9

10

12

14

7

8

8

8

250



6

10

12

14

5

8

8

8

500



4

7

11

14

3

4

8

8

1000





5

7

12





5

6

1600







5

9







5

2000







4

7







4



Also available with specifications outside this standard offering on a case-by-case basis.

Benefits

The Konecranes KBK aluminium workstation lifting systems provides dependable lifting throughout your operations with the following product benefits:

•    Easily combined with electric chain hoists, pneumatic lifting devices or manual hoists for a versatile workstation lifting system
•    High durability and productivity
•    Light and ergonomic for the ultimate user experience
•    Fast installation with standardized profiles and bolt-on connections
•    Lighter than steel by about 50% and with less rolling resistance
•    Minimal maintenance required
•    Easily customized
•    Optimal for clean environments
•    Maximized working area below the crane
•    Comprehensive service solutions to maximize daily efficiency, safety and performance

Consult our Crane Advisor for Konecranes KBK aluminium workstation lifting systems

Crane Advisor is an online tool that offers recommendations based on your specific lifting-application needs. Visit Crane Advisor to know more details about Konecranes KBK aluminium workstation lifting systems.

Global service tailored to your needs

Your Konecranes KBK aluminium workstation lifting system will receive reliable, local support backed up by a global network of dedicated, skilled professionals. Konecranes is a world-renowned leader in equipment manufacturing, with more than 600 service locations in nearly 50 countries. Our experience, scale and know-how can provide you with dependable and durable lifting machines with a good return on your investment for many years to come.
