Product Features
The Konecranes KBK steel workstation lifting system has the following product features:
• Strong and robust steel runways and bridges
• Modular system with multiple profile sizes
• Different system configurations, including:
-
monorail
-
single and double girder bridges with articulated or rigid movement
-
freestanding structures
-
telescopic cranes
-
installations for manipulator handling
• Manual or motorized trolleys and bridges
• Smooth-running trolleys with low rolling resistance
• Service hatch for easy trolley inspection and maintenance
• Energy supply via festoon or integrated conductor lines
• Low headroom available
• Long suspension distances and span lengths
• Dust and dirt protection
• Can be combined with aluminium runways and bridges
Technical specifications
The Konecranes KBK steel workstation lifting system has the following standard technical specifications:
-
Intended for indoor use
-
Design follows EC machinery directives
-
Ambient temperature range limits -10°C to +40°C
-
Corrosion category at least C2-M (acc. to DIN EN ISO 12944)
-
Crane control via pendant or radio
-
Up to 6 bridges on one runway
Performance data for single-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
|
80 |
3 |
6 |
8 |
8 |
|
5 |
8 |
8 |
8 |
|
125 |
3 |
5 |
8 |
8 |
14 |
4 |
6 |
8 |
8 |
|
250 |
|
3 |
7 |
8 |
13 |
2 |
4 |
7 |
8 |
|
500 |
|
2 |
4 |
7 |
11 |
2 |
3 |
4 |
6 |
|
1000 |
|
|
2 |
4 |
7 |
|
|
3 |
4 |
|
1600 |
|
|
|
|
6 |
|
|
|
3 |
|
2000 |
|
|
|
|
5 |
|
|
|
3 |
Performance data double-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
| Steel | Aluminium | ||||||||
|
|
5 |
9 |
10 |
12 |
14 |
7 |
8 |
8 |
8 |
|
250 |
|
6 |
10 |
12 |
14 |
5 |
8 |
8 |
8 |
|
500 |
|
4 |
7 |
11 |
14 |
3 |
4 |
8 |
8 |
|
1000 |
|
|
5 |
7 |
12 |
|
|
5 |
6 |
|
1600 |
|
|
|
5 |
9 |
|
|
|
5 |
|
2000 |
|
|
|
4 |
7 |
|
|
|
4 |
Also available with specifications outside this standard offering on a case-by-case basis.
Benefits
The Konecranes KBK steel workstation lifting system provides dependable lifting throughout your operations with the following product benefits:
• Easily combined with electric chain hoists, pneumatic lifting devices or manual hoists for a versatile workstation lifting system
• Ideal for heavy-duty operations
• Adaptable for all kinds of workstation applications
• Long suspension distances and travel over long span lengths
• Easy installation, modification and extension
• Maximized working area below the crane
• Long lifetime and reduced maintenance costs
• Fast installation with standardized profiles and bolt-on connections
• Comprehensive service solutions help increase efficiency, safety and performance
Consult our Crane Advisor for XK-S crane
Crane Advisor is an online tool that offers recommendations based on your specific lifting-application needs. Visit Crane Advisor to know more details about XK-S aluminum workstation cranes.
