Product features
The Konecranes KBK aluminium workstation lifting systems has the following product features:
- Light and durable anodized aluminum structure
- Modular system with multiple profile sizes
- Different system configurations, including:
- monorail
- single and double girder bridges with articulated or rigid movement
- freestanding structures
- telescopic cranes
- installations for manipulator handling
- Manual or motorized trolleys and bridges
- Smooth-running trolleys with low rolling resistance
- Service hatch for easy trolley inspection and maintenance
- Energy supply via festoon or integrated conductor lines or energy chain
- Low headroom available
- Lifetime protection against corrosion
- Can be combined with steel runways and bridges
Technical Specifications
The Konecranes KBK aluminium workstation lifting system has the following standard technical specifications:
-
Intended for indoor use
-
Design follows EC machinery directives
-
Ambient temperature range limits -10°C to +40°C
-
Corrosion category at least C2-M (acc. to DIN EN ISO 12944)
-
Crane control via pendant or radio
-
Up to 6 bridges on one runway
Performance data for single-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
|
80 |
3 |
6 |
8 |
8 |
|
5 |
8 |
8 |
8 |
|
125 |
3 |
5 |
8 |
8 |
14 |
4 |
6 |
8 |
8 |
|
250 |
|
3 |
7 |
8 |
13 |
2 |
4 |
7 |
8 |
|
500 |
|
2 |
4 |
7 |
11 |
2 |
3 |
4 |
6 |
|
1000 |
|
|
2 |
4 |
7 |
|
|
3 |
4 |
|
1600 |
|
|
|
|
6 |
|
|
|
3 |
|
2000 |
|
|
|
|
5 |
|
|
|
3 |
Performance data double-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
| Steel | Aluminium | ||||||||
|
|
5 |
9 |
10 |
12 |
14 |
7 |
8 |
8 |
8 |
|
250 |
|
6 |
10 |
12 |
14 |
5 |
8 |
8 |
8 |
|
500 |
|
4 |
7 |
11 |
14 |
3 |
4 |
8 |
8 |
|
1000 |
|
|
5 |
7 |
12 |
|
|
5 |
6 |
|
1600 |
|
|
|
5 |
9 |
|
|
|
5 |
|
2000 |
|
|
|
4 |
7 |
|
|
|
4 |
Also available with specifications outside this standard offering on a case-by-case basis.
Benefits
The Konecranes KBK aluminium workstation lifting system provides dependable lifting throughout your operations with the following product benefits:
• Easily combined with electric chain hoists, pneumatic lifting devices or manual hoists for a versatile workstation lifting system
• High durability and productivity
• Light and ergonomic for the ultimate user experience
• Fast installation with standardized profiles and bolt-on connections
• Lighter than steel by about 50% and with less rolling resistance
• Minimal maintenance required
• Easily customized
• Optimal for clean environments
• Maximized working area below the crane
• Comprehensive service solutions to maximize daily efficiency, safety and performance
Consult our Crane Advisor for Konecranes KBK aluminium workstation lifting systems
Crane Advisor is an online tool that offers recommendations based on your specific lifting-application needs. Visit Crane Advisor to know more details about Konecranes KBK aluminium workstation lifting system.
