Product Features
The Konecranes KBK steel workstation lifting system has the following product features:
• Strong and robust steel runways and bridges
• Modular system with multiple profile sizes
• Different system configurations, including:
-
monorail
-
single and double girder bridges with articulated or rigid movement
-
freestanding structures
-
telescopic cranes
-
installations for manipulator handling
• Manual or motorized trolleys and bridges
• Smooth-running trolleys with low rolling resistance
• Service hatch for easy trolley inspection and maintenance
• Energy supply via festoon or integrated conductor lines
• Low headroom available
• Long suspension distances and span lengths
• Dust and dirt protection
• Can be combined with aluminum runways and bridges
Technical specifications
The Konecranes KBK steel workstation lifting system has the following standard technical specifications:
-
Intended for indoor use
-
Design follows EC machinery directives
-
Ambient temperature range limits -10°C to +40°C
-
Corrosion category at least C2-M (acc. to DIN EN ISO 12944)
-
Crane control via pendant or radio
-
Up to 6 bridges on one runway
Performance data for single-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
|
80 |
3 |
6 |
8 |
8 |
|
5 |
8 |
8 |
8 |
|
125 |
3 |
5 |
8 |
8 |
14 |
4 |
6 |
8 |
8 |
|
250 |
|
3 |
7 |
8 |
13 |
2 |
4 |
7 |
8 |
|
500 |
|
2 |
4 |
7 |
11 |
2 |
3 |
4 |
6 |
|
1000 |
|
|
2 |
4 |
7 |
|
|
3 |
4 |
|
1600 |
|
|
|
|
6 |
|
|
|
3 |
|
2000 |
|
|
|
|
5 |
|
|
|
3 |
Performance data double-girder cranes:
|
100 |
I |
II-L |
II |
II-H |
A12 |
A16 |
A18 |
A22 |
|
|
LOAD CAPACITY [KG] |
GIRDER LENGTH (M) |
||||||||
| Steel | Aluminium | ||||||||
|
|
5 |
9 |
10 |
12 |
14 |
7 |
8 |
8 |
8 |
|
250 |
|
6 |
10 |
12 |
14 |
5 |
8 |
8 |
8 |
|
500 |
|
4 |
7 |
11 |
14 |
3 |
4 |
8 |
8 |
|
1000 |
|
|
5 |
7 |
12 |
|
|
5 |
6 |
|
1600 |
|
|
|
5 |
9 |
|
|
|
5 |
|
2000 |
|
|
|
4 |
7 |
|
|
|
4 |
Also available with specifications outside this standard offering on a case-by-case basis.
Benefits
The XK-S provides dependable lifting throughout your operations with the following product benefits:
• Easily combined with electric chain hoists, pneumatic lifting devices or manual hoists for a versatile workstation lifting system
• Ideal for heavy-duty operations
• Adaptable for all kinds of workstation applications
• Long suspension distances and travel over long span lengths
• Easy installation, modification and extension
• Maximized working area below the crane
• Long lifetime and reduced maintenance costs
• Fast installation with standardized profiles and bolt-on connections
• Comprehensive service solutions help increase efficiency, safety and performance
Consult our Crane Advisor for Konecranes KBK steel workstation lifting systems
Crane Advisor is an online tool that offers recommendations based on your specific lifting-application needs. Visit Crane Advisor to know more details about Konecranes KBK steel workstation lifting systems.
